3 port boost control solenoids are the go-to for the majority of boost control applications, they allow for precise control of boost and boost levels can be raised to around 2-3 times the spring pressure of the wastegate.
For higher boost applications consider our 4-Port boost control solenoid.
Features:
Compatible with all Link ECU's.
It can be used with single or multiple wastegates (Using a T junction).
Compatible with internal or external wastegates.
Fast and consistent response times.
High shifting forces.
MAC 35 series - Rugged, reliable and long operational life.
Short stroke, high flow.
Balanced poppet, immune to variations of pressure.
We recommend starting with a PWM Frequency of 20Hz for this Boost control solenoid. A detailed description of setting up boost control can be found in the help file in our PCLink software which is available for free download.
Specifications:
MAC 35 series.
120 PSI max.
1/8' BSPPL.
12 VDC (5.4W).
18' (45cm) coil leads.
Includes 3 x 1/8 BSP hose tail fittings for easy connection.
